G.hn Ethernet over Coax System Receiver & WiFi 6 Access Point | BEW-100
BLANKOM
The new BLANKOM G.hn Ethernet over Coax System consists of BEM-100 series transmitter, BES-100 series receiver, BEW-100 Wi-Fi 6 access point and the related distribution accessories like filter and splitter.
The system can carry Ethernet signals at up to 1 Gbps speed both ways over a coaxial SMATV distribution network. The biggest benefit is that the existing coaxial network in a building can be used as a LAN. You can keep using your existing coaxial cable infrastructure, even your existing amplifiers.
The existing coaxial network will support systems such as IPTV, Internet Access, VoIP Telephony, Access Control, and other IP-based systems, along with the ongoing terrestrial TV service.
| Outstanding features | Use existing coaxial cable |
|---|---|
| Ordering guide | BEW-100 Receiver & WiFi 6 Access Point |
G.hn Ethernet over Coax System Receiver & Wi-Fi 6 Access Point / BEW-100
Receiver and Wi-Fi Access Point combined for the G.hn Ethernet over Coax system.
BLANKOM BEW-100 G.hn Ethernet over Coax System Receiver + Wi-Fi 6 Access Point
BLANKOM BEW-100 G.hn Ethernet over Coax System Receiver + Wi-Fi 6 Access Point front
BLANKOM BEW-100 G.hn Ethernet over Coax System Receiver + Wi-Fi 6 Access Point rear
Accessories:
Return Path Filter: Return-path filter GRPF-200 to use a standard amplifier for TV Signals > 300 Mhz.
Standard CATV Amplifier/Splitter/Combiner/Taps can be used from the public market as long as they serve the frequency range needed in both ways: 2 – 862MHz.
Application Example 1: Ethernet over Coax with Satellite Multiswitch System
BLANKOM G.hn Ethernet over Coax System Application with Satellite Multiswitch
Application Example 2: Ethernet over Coax with Satellite House design
BLANKOM G.hn Ethernet over Coax System Application House design
Application Example 3: Ethernet over Coax with Satellite Hospital/Hotel/Residence design
BLANKOM G.hn Ethernet over Coax System Application Hospital/Hotel/Residence design
Gigabit for everyone – the BLANKOM G.hn EoC solution!
With the BLANKOM G.hn Ethernet over Coax system, you can network your equipment via the existing coaxial cables (i.e. the TV cabling) in your home. This enables a quick and uncomplicated entry into the multimedia future. Your guests can enjoy high-speed Internet (up to symmetrical gigabit speed), reliable Wi-Fi, free-to-guest TV, older pay-per-view content, IPTV, HD streaming and other hotel services
- Installation possible during operation (short migration time)
- No extensive construction work
- No dirt, no noise
- No further fire protection measures necessary
- Reliable high-speed network for WLAN and other services
- Technology partnership with leading network equipment providers such as HPE Aruba, Cisco Meraki, Ruckus and Cambium Networks
- Certified by Marriott GPNS for HSIA, IHG Studio, IHG Connect, Hyatt, Caesars Entertainment and other major chains and hotels
SPECIFICATIONS
Standards
- IEEE 802.3/802.3u/802.3ab
- ITU-T G.9960/G.9961 G.hn over Coax
- IEEE 802.11 a/b/g/n/ac/ax
- hn Frequency: 2 ‒ 200MHz
Data Rates
- hn: up to 1,7 Gbps
- Ethernet: 10/100/1000 Mbps
- WiFi: 5 GHz up to 1200 Mbps
2.4 GHz up to 300 Mbps
Transmission Range
- hn: up to 70 dBm attenuation
- Ethernet: maximum 100 meters
Interface
- F connectors: TV+Data port / TV port
- Antennas: Built-in Antenna
- Ethernet port: LAN (10/100/1000Mbps)
- Reset button: Pair/Reset (for G.hn)
- WPS button: WPS /Reset (for WiFi)
General
- Power external PSU 12 V DC
- Dimensions: 143 x121 x29mm (without rack)
Environmental for operating:
- Temperature 0°C – 40°C (32°F – 104°F)
- Humidity 10% – 95% RH
Environmental for storage:
- Temperature -10°C – 70°C (14°F – 158°F)
- Humidity 10% – 95% RH
Specifications are subject to change without prior notice.
