Active Optical Fibre HDMI Hybrid Cable (AOC) HDMI-4K-8000
IRENIS HDMI-4K-8000

IRENIS Active HDMI Hybrid Cable (AOC) for Long Distance

Long-Distance Ultra High-Speed Active Optical HDMI Hybrid Cable (AOC), 4K, suitable for up to 60 Hz resolution at 4K for up to 100 metre length

Request a quote for HDMI-4K-8000
AvailabilityShips from Germany
EnquiriesWrite to us — an engineer answers, not a call centre

At a glance

Key data, as supplied by engineering
Brand
  • IRENIS
Model
  • HDMI-4K-8000
Available Lengths
  • 7.50m
  • 10m
  • 15m
  • 20m
  • 30m
  • 40m
  • 50m
  • 75m
  • 100m
Available Colors
  • Black

Overview

Product description

Long-Distance Ultra High-Speed Active Optical HDMI Hybrid Cable (AOC), 4K, suitable for up to 60 Hz resolution at 4K for up to 100 metre length

With the Active Optical HDMI Hybrid Cable (AOC) you transfer your UHD data lossless over long distances.

In set there is a pulling capsule, you put the HDMI D plug in.

An eyelet is attached to the capsule to fixate your cable laying tool.

Now the HDMI D connector is protected and can be pulled through a ductwork.

pdf icon

Download data sheet

Features & capabilities

  • Connections: HDMI A plug to HDMI D plug (19P19C)
  • Incl. Adapter HDMI D jack to HDMI A plug (with DC jack for 5V infeed), USB power cable (USB A plug to DC plug), plastic pulling capsule
  • Resolution up to: 4K2K (60 Hz), 4K2K (30 Hz), 1080p (3D)
  • Supports colour sampling in 4:4:4, 4:2:2 and 4:2:0 format
  • Supports: HDR10, HLG, HDCP 2.2, HDCP 1.4, 3D, EDID, HEC, CEC, ARC
  • Bandwidth up to: 18 Gbps
  • Supports transmission of uncompressed HDMI 2.0 payload of 17.819 Gbps
  • Material cable sheath: PVC
  • Plug material: zinc alloy, gold-plated
  • Contact surface: gold-plated pins
  • Cover: moulded
  • Kink protection: Yes
  • Cable structure: AWG 24-30 / OM3
  • Wire material: Copper / POF
  • Colour cable: black
