IRENIS Cat. 6A FTP Armoured Patch cord
Cat. 6A U/FTP Armored bare copper, aluminum foil-shielded PVC cable with stainless steel armoring. Despite the armored cable sheath, which protects the inside of the cable, the cable is extremely flexible.
At a glance
Key data, as supplied by engineering- IRENIS
- CAT6F-2000
- 50cm
- 1m
- 1.50m
- 2m
- 3m
- 5m
- 7.50 m
- 10m
- 15m
- 20m
- 25m
- 30m
- Gray
Overview
Product description
Cat. 6A U/FTP Armored bare copper, aluminum foil-shielded PVC cable with stainless steel armoring.
Despite the armored cable sheath, which protects the inside of the cable, the cable is extremely flexible.
Perfect for camera technology, lighting engineering, sound engineering, stagecraft, trade fair technology, conference technology, or other media technology.
The Cat. 6A FTP armored cables are designed for professional use.
Despite the stainless steel armored cable sheath, which protects the inside of the cable, the cable is extremely flexible.
Perfect for camera technology, lighting engineering, sound engineering, stagecraft, trade fair technology, conference technology, or other media technology.
Category 6A cable is specified for 500 MHz and has improved alien crosstalk characteristics, allowing 10GBASE-T to be run for 100-meter (330 ft) maximum distance.
Features & capabilities
- Patch cord Cat. 6A U/FTP PIMF
- Cable size: 28/7 AWG
- Connections: RJ45 plug to RJ45 plug
- Compatible with 10GBASE-T, 1000BASE-T and below
- Transmission frequency up to: 500 MHz
- Bandwidth up to: 10 Gbps
- Pin assignment: EIA/TIA 568B
- Specification: Cat. 6A
- Backwards-compatible versions: Cat. 6, Cat. 5E and below
- Shielding : ALU foil laminated PIMF (100% density)
- Shielding class: U/FTP (PIMF)
- Wire material: copper
- Wire type: stranded
- Wire number: 8 (4 x 2 twisted pair), with drain wire
- Plug: assembled, Interlock Plug
- Contact surface: pins gold-plated 50µ
- Plug material: nylon, copper alloy
- Kink protection: yes
- Latch protection: yes
- Cable type: round cable
- Material cable sheath 1: PVC
- Material cable sheath 2: stainless steel
- Material cable sheath 3: high elasticity PVC, flexible
- Cable sheath outer diameter (approx.): 7.3mm
- Min. bending radius (Static): 10 x cable OD
- Min. bending radius (Dynamic): 15 x cable OD
- Colour cable: gray
- Colour plug inlay: black
