IRENIS Active DisplayPort 1.4 (AOC) Cable, 8K, up to 100 meter length
DisplayPort 1.4 cable assembly, up to 100 meters cable length. With the DisplayPort 1.4 cable, you connect, e.g., your graphics card with a monitor, TV, or video projector at up to 8K resolution.
At a glance
Key data, as supplied by engineering- IRENIS
- DP14-4000
- 7.5m, 10m, 15m, 20m, 30m, 40m, 50m, 75m, 100m
- Black
Overview
Product description
DisplayPort 1.4 cable assembly, up to 100 meters cable length.
With the DisplayPort 1.4 cable, you connect, e.g., your graphics card with a monitor, TV, or video projector at up to 8K resolution.
Active DisplayPort 1.4 (AOC) Cable, 8K, Long Distance | DP14-4000
The active optical DisplayPort hybrid cable (AOC) transmits your multimedia signal even over long distances, lossless.
This cable supports a maximum bandwidth of 32.4 Gbps which can be a resolution of 7680 x 4320 at 60 Hz, 5120 x 2880 at 120 Hz or 3840 x 2160 at 240 Hz and a color sampling of 4:2:0.
Higher color sampling reduces the frame rate (Hz).
Features & capabilities
- DisplayPort Version: 1.4
- Connections: DisplayPort plug to DisplayPort plug (20P20C)
- Resolution up to 8K (60Hz), 5K (120Hz), 4K2K (240Hz)
- Supports color sampling in 4:4:4, 4:2:2 and 4:2:0 formats
- Supports: HDR10, HDCP 2.2, HDCP 1.4, 3D, EDID, Adaptive Sync, DSC, HBR3
- Bandwidth up to 32,4 Gbps
- Backwards-compatible Versions: 1.3, 1.2 and 1.1
- Material cable sheath: PVC
- Diameter of cable (ca.): 4.8 mm
- Plug material: zinc alloy, gold-plated
- Contact surface: gold-plated pins
- Plug housing: metal
- Cover: moulded
- Kink protection: Yes
- Wire material: Copper/POF
- Color cable: black
Get a quote for the DP14-4000
Tell us the source, the destination and the number of channels. We reply in writing with a configuration, part numbers and pricing — our engineers answer from the bench, so a written enquiry reaches the right person faster than a phone call.
