IRENIS HDMI Cable HDMI-3000
IRENIS HDMI-3000

IRENIS HDMI Cable 4K/Full HD

Economic HDMI cable with excellent performance. 4K up to 7.5 m length and Full HD over 10 m length.

Request a quote for HDMI-3000
AvailabilityShips from Germany
EnquiriesWrite to us — an engineer answers, not a call centre

At a glance

Key data, as supplied by engineering
Brand
  • IRENIS
Model
  • HDMI-3000
Available Lengths
  • 50cm
  • 75cm
  • 1m
  • 1.50m
  • 2m
  • 3m
  • 5m
  • 7.5m
  • 10m
  • 15m
  • 20m
Available Colors
  • Black
Resolution
  • up to 4K2K (60Hz), 4K2K (30Hz), 1080p (3D) for 50cm
  • 75cm
  • 1m
  • 1.50m
  • 2m cables
  • up to 4K2K (30Hz), 1080p (3D) for 3m
  • 5m
  • 7.5m cables
  • up to 1080p (60Hz) (Full HD) for 10m
  • 15m
  • 20m cables

Overview

Product description

Economic HDMI cable with excellent performance. 4K up to 7.5 m length and Full HD over 10 m length.

With an HDMI cable, you connect, e.g., a set-top box with a TV, monitor, or video projector.

An HDMI cable transmits digital picture and audio signals.

HDMI is probably the most commonly used multimedia interface; nearly all HD players use it.

pdf icon

Download data sheet

Features & capabilities

  • Connections: HDMI-A plug to HDMI-A plug

For lengths: 50 cm, 75 cm, 1 m, 1.5 m, 2 m

  • Resolution up to: 4K2K (60 Hz), 4K2K (30 Hz), 1080p (3D)
  • Bandwidth up to: 18Gbps

For lengths: 3m, 5m, 7.5m

  • Resolution up to: 4K2K (30Hz), 1080p (3D)
  • Bandwidth up to 10.2 Gbps

For lengths of 10m, 15m, and 20m

  • Resolution up to 1080p (60 Hz) (Full HD)
  • Bandwidth up to 4.95Gbps

Common specifications for all lengths:

  • Supports color sampling in 4:4:4, 4:2:2, and 4:2:0 formats
  • Supports: ARC, HDCP, 3D, CEC, HEC, HDR10, HLG
  • HDMI Standard: High Speed with Ethernet
  • Number of shieldings: 3
  • Shielding 1: ALU foil laminated PIMF (5 pairs)
  • Shielding 2: ALU foil (100% density)
  • Shielding 3: ALU braid
  • Cable Structure: AWG 30
  • Wire material: copper mixture
  • Plug: molded type
  • Plug material: CuZnNi, gold-plated
  • Contact surface: gold-plated
  • Plug housing: PVC
  • Material cable sheath: PVC
  • Diameter of cable (approx.): 6.5 mm
  • Color Cable: black
