Speaker Cable, Parallel
Flexible, flame-resistant, oxygen-free copper speaker cables for demanding applications. Easily separated conductors are convenient for connection to connectors or screw terminals of loudspeakers or amplifiers.
At a glance
Key data, as supplied by engineering- Black
- 100m
- 250m
- 500m
- BLANKOM cables are available through our distributors
- For direct ordering, MOQ and MOV conditions apply
- White Label and OEM manufacturing possible
Overview
Product description
Flexible, flame-resistant, oxygen-free copper speaker cables for demanding applications.
Easily separated conductors are convenient for connection to connectors or screw terminals of loudspeakers or amplifiers. The professional version of high-performance cable is designed for use in studios and stage spaces.
Each conductor of the SFL Y cable consists of numerous cores, which ensures a low resistance value and, as a result, high-quality reproduction of the sound signal. The outer shell is made of elastic PVC. The conductors are made of fine-wire, oxygen-free copper. This ensures high flexibility of cables and precise linearity of the sound spectrum.
• popular parallel design of professional acoustic cable
• convenient cable stripping and connection
BLANKOM Parallel Speaker Cable | SFL-Y2075S, SFL-Y2150S, SFL-2250S, SFL-2400S
The BLANKOM parallel speaker cable is best for medium- and high-power transfer applications. The parallel construction, finely twisted strands in each conductor, and flexible covering provide durability and a high degree of flexibility and give the cable remarkable characteristics.
1.50 and 2.50 mm² speaker cables are best suited to medium-power transfer.
4.00 mm² speaker cable is best suited to high-power transfer. The low conductor resistance provides for the installation of high-power systems. For example, these are the exact choices for the inputs of the bases.
Design
- Conductors
- Model SFL-Y2075S: 18 AWG stranded (42x 0,15 mm), bare copper (OFC)
- Model SFL-Y2150S: 15 AWG stranded (84x 0,15 mm), bare copper (OFC)
- Model SFL-Y2250S: 13 AWG stranded (140x 0,15 mm), bare copper (OFC)
- Model SFL-Y2400S: 11 AWG stranded (224x 0,15 mm), bare copper (OFC)
- Dielectrics
PVC YI2, to DIN VDE 0207 part 4
Two cores, - Jacket
Matt PVC-Soft, black YM2, to DIN VDE 0207 part 5- Model SFL-YY215B: 2.4 x 4.9 mm
- Model SFL-YY215B: 3.1 x 6.4 mm
- Model SFL-YY225B: 3.6 x 7.4 mm
- Model SFL-YY240B: 4.5 x 9.7 mm
Construction
Specifications are subject to change without prior notice.
Features & capabilities
- Parallel Type
- Oxygen-free bare copper
- Flame Resistant
- High Degree Flexible
- Meter marking
- Professional quality
Ordering guide
Exact part numbers for the quotationOrdering guide
