BLANKOM SDE-16265 Full HD IP Encoder Streamer

16 Channel, 3G-SDI to IP Encoder & Streamer | SDE-16265

BLANKOM SDE-16265

16-channel 1080p (2K) high-definition (HD) encoder & streamer for live broadcasting platforms and video-over-IP applications. Up to 1920*1080@60fps Full-HD resolution. Very stable operation on multicast distribution on local area networks. Suitable for video-over-IP application through the internet. 4 IP output streams per channel at the same time with different resolutions, e.g. for LAN, YouTube, Facebook, and Twitch simultaneously.

All BLANKOM encoders offer perfect image quality and stable system operation at an affordable price.

Inputs

16x SDI, SDI embedded audio, external analog stereo input by 3.5mm jacks
Outputs

16x GbE IP (up to 4 IP Streams per channel), SDI Loop-through output
Outstanding features

SDE-16265 supports a maximum resolution of 1920×1080@60fps at each input, and at each output. It works with stream protocols SRT / HTTP / HLS / FLV / RTSP / RTMP / RTMPS / UDP/RTP (Unicast/Multicast) and ONVIF. The SDE-16265 is compatible with online live-streaming services, such as YouTube, Facebook, Ustream, and others.
Ordering options

SDE-16265: 16x SDI input, loop-through SDI output
SDE-08265:  8x SDI input, loop-through SDI output

Share this product

16 Channel 1080p60 3G-SDI (Full HD) H.265 (HEVC) and H.264 Streaming Encoder with 4 Streams Output per Channel



BLANKOM SDE-16265 streaming encoder serves the distribution of SD and HD TV video content through IP networks in digital quality. The live video can be received by Internet media servers, by TV sets with IPTV set-top boxes, and on PCs and tablets with VLC Player.

BLANKOM SDE-16265 Full HD IP Encoder Streamer

BLANKOM SDE-16265 Full-HD IP-Encoder Streamer



  • H.265 / H.264 Encoder & IP Streamer combined
  • 3G-SDI input and loop-through 3G-SDI output
  • 2 versions
    SDE-16265: 16x SDI input with loop-through SDI output
    SDE-08265:  8x SDI input with loop-through SDI output
  • Stereo audio input on each channel
  • 4 IP streams output on each channel
  • Modular structure
  • Dual power supply with 1:1 redundancy
  • Stable and effective embedded HiLinux OS
  • HD Resolution 1080p60 (2Kp60), 1080i, 720p and scaling down to 176×144
  • IP output: HTTP, RTSP, RTMP, RTMPS, UDP/RTP, FLV, ONVIF, HLS, SRT; unicast/multicast output.
  • Low latency: 700 … 800 ms (800 ms in avg.) (RTMP)
  • Distribution of Video camera, PC Monitor, dif. STB, DVD / Blu-ray player content over LAN, WAN, or Internet
  • Live stream broadcast, Digital signage, Video conferencing, RTSP support
  • Video-over IP applications
  • IPTV/OTT/Info-Channel applications
  • Local IPTV on LAN applications, Corporate IPTV, Hotel IPTV, Campus IPTV, Education IPTV
  • VLC and FFmpeg mode selectable
  • VBR/CBR bitrate mode encoding
  • Logo insertion (as *.bmp file) and text insertion feature on the main stream & on secondary streams
  • Streams to Ustream, Atlas™, Wowza®, and Adobe® Flash® Servers, www.vmix.com conform to YouTube, Vimeo, X, Facebook, Twitch live broadcast platforms
  • HLS encoding feature, Android and iOS mobile devices compatible

    •





BLANKOM HD Encoder Streamers Application Diagram

B2B application examples showcasing how the 16-blade modular architecture, H.265 compression, and dual-power redundancy of the SDE-16265 solve large-scale video distribution requirements:

  • Carrier-Grade Central IPTV Headend Ingestion for Hotels and Resorts: Large-scale multi-building resort complexes or cruise ships require consolidating all video streaming infrastructure inside a secure central rack. By deploying the SDE-16265, engineers can ingest up to 16 high-definition video feeds into a single 3U cabinet space. By encoding the streams into H.265 UDP Multicast transport streams, the hotel slashes its local network bandwidth consumption by up to 50% compared to older H.264 setups, while the dual redundant industrial power supplies guarantee zero black-screen downtime for guest room TVs.

  • High-Density Multi-Camera Municipal and Courtroom Recording: Large municipal city halls or judicial complexes manage dozens of active cameras across multiple courtrooms and committee chambers simultaneously. The SDE-16265 acts as a centralized ingest hub, capturing 16 independent camera feeds in high-density H.265 format. Utilizing its 4-stream per channel capability, each courtroom blade can concurrently broadcast an RTMP feed to a public transparency portal, an RTSP feed to the main security monitoring wall, and separate high-efficiency master backup lines to an internal Network Video Recorder (NVR) for legal archiving compliance.

  • Centralized Enterprise Corporate Town Hall and Multi-Room Distribution: Multinational corporate headquarters often run independent video networks across different departments, training rooms, and executive boardrooms. By installing the SDE-16265 in the primary data center, the internal AV team routes 16 independent high-definition inputs directly into the 3U chassis. Selected blades can be optimized to stream secure low-latency H.265 SRT feeds over WAN to international branch offices, allowing high-quality video delivery over volatile public internet links with minimal bitrates.

  • Comprehensive University NOC Lecture Capture and Campus IPTV: In a university Network Operations Center (NOC), managing decentralized streaming hardware from 16 different campus lecture halls is highly inefficient. The high-density SDE-16265 centralizes this process by aggregating 16 independent high-definition camera and visualizer inputs into a unified 3U infrastructure. Each isolated module processes its own room feed into universally compatible H.264 or high-efficiency H.265 multicast streams, allowing students anywhere on the local campus network to stream live educational feeds using standard open-source media players like VLC on any tablet or PC.

  • Teleport Contribution and DSNG Mobile Broadcasting Vans: Digital Satellite News Gathering (DSNG) trucks and satellite teleport stations operate under volatile conditions with zero tolerance for power failures or excessive bandwidth costs. Broadcast crews install the rugged SDE-16265 inside their mobile rack units to handle up to 16 camera or production desk feeds simultaneously. Powered directly by the dual industrial power supply connected to independent backup generator circuits, the unit compresses the material into robust H.265 SRT and UDP transport streams, ensuring stable, bandwidth-optimized contribution transmission back to the main studio headend under heavy environmental demands.



BLANKOM SDE-16265 IPTV encoder is designed for TV signal distribution in excellent quality over LAN and INTERNET.

The H.264 and H.265 (HEVC)  compression technology features low-latency and low bit rates for IPTV/OTT systems. The highly efficient encoding chips save bandwidth costs through all their resolution ranges.

Distribution of SD and HD TV channels through the IPTV/OTT network using state-of-the-art IP technology from almost any kind of video input.

Excellent video and audio quality.

High reliability. No regular service and maintenance are needed during operation.

From 1 input signal, 4 entirely different streams can be generated. The main stream can have up to Full HD (1080p), and the secondary streams up to 720p HD resolution.

On screen logo and text insertion. Through the HLS encoding feature, Android and iOS mobile devices are compatible.

The uni- and multicast streams can be assigned with DVB-conform table content to allow the integration into multiplexes of IP to DVB-Modulators.

The easy configuration is designed by a simple web interface application compatible with nearly every browser.

BLANKOM SDE-16265 Full HD IP Encoder Streamer

BLANKOM SDE-16265 Full-HD IP Encoder Streamer



BLANKOM SDE-08265 Full HD IP Encoder Streamer

BLANKOM SDE-08265 Full-HD IP Encoder Streamer





Function: H.265 (HEVC) & H.264 Encoder and IP Streamer, 16 Channels, Dual Power Supply

INPUT

  • 16 SDI inputs with loop-through SDI output (8x SDI inputs option)
  • Input Resolution: 1080p, 1080i, 720p and below
  • Separate audio input with level adjustment (3.5 mm L/R analog audio line in)
  • Embedded audio from the SDI signal or external audio can be selected

OUTPUT

  • Simultaneous 4 different stream outputs per channel (main stream and 3 secondary streams)
  • SDI loop through output
  • Each stream can be H.265 (HEVC) or H.264 encoded
  • Video data rate: 0.1 Mbps ~ 32 Mbps
  • Video frame rate: 5 ~ 60 fps
  • Bit rate control: VBR, CBR
  • Output Resolution 1080p, 1080i, 720p and below (max 1080p@60fps on main stream)
  • Mainstream output resolution support: 1920×1080, 1680×1056, 1280×720, 1024×576, 850×480, 720×576, 720×540, 720×480, 720×404, 704×576, 640×480, 640×360, 608×448, 544×480, 480×480, 480×384, 480×360, 480×320, 480×272, 480×270, 400×320, 400×224, 352×480, 352×228, 320×256, 320×240, 320×180, 240×180, 176×144.
  • Low latency: 700 … 800 ms (800 ms in avg.) (RTMP)

SYSTEM

  • Protocol HTTP / SRT / HLS / FLV / RTSP / RTMP / RTMPS / UDP/ RTP (Unicast/Multicast) Stream Protocols and ONVIF
  • Video encoder HEVC (H.265) or H.264 (MPEG-4, AVC) high, main, baseline profile, MJPEG/JPEG baseline
  • Audio encoder AAC/AAC+/AAC++/MP3/MP2/AC3 G711
  • Data interface RJ45, 1 Gbps Ethernet interface, control over web browser
  • Rate control CBR/VBR
  • GOP Structure IBBP Adv
  • Pretreatment: De-interlacing, Noise reduction, Sharpening
  • Sampling rate Auto
  • Audio Bitrate: 48K/64K/96K/128K/160K/192K
  • Audio sampling precision: 24 bit
  • Audio Data Rate: 12 kbps ~ 640 kbps
  • User interface WEB GUI
  • Logo (as *.bmp file) and Text insertion feature on main stream & on 2nd stream
  • Firmware upgrade support

GENERAL

  • Power supply 12V DC, 25A
  • Dimensions: 19 inch, 3RU (483 × 300 × 44.5 mm)
  • Weight: 6.5 kg

Specifications are subject to change without prior notice.



The BLANKOM SDE-16265 series is a high-density, broadcast-grade hardware encoding and streaming solution designed for professional television studios, OB vans, master control rooms, and IPTV headends. It ingests high-bandwidth uncompressed digital baseband signals from multiple SDI sources simultaneously and compresses the video/audio payloads in real time into optimized digital IP transport streams.

To precisely address distinct system integration layouts and input density requirements, the product family consists of two specialized hardware versions:

  • SDE-16265: Features 16 physical 3G-SDI inputs equipped with 16 corresponding independent SDI loop-through outputs.

  • SDE-08265: Features 8 physical 3G-SDI inputs equipped with 8 corresponding independent SDI loop-through outputs.

Both the SDE-16265 and SDE-08265 incorporate a physical SDI loop-through output on each individual channel. The primary purpose of this architecture is to provide a zero-latency, completely unaltered pass-through of the original incoming SDI baseband video signal. This allows broadcast engineers and camera operators to route the source video directly to a local multi-viewer, confidence monitor, or local production hardware on-site, entirely eliminating the need for external, costly SDI distribution amplifiers (Splitters).

The hardware input interface is engineered to comply with high-definition professional broadcast standards, natively supporting 3G-SDI configurations with operational bitrates reaching up to 3 Gbps. This high-speed capability ensures uncompromised syntax extraction from full HD broadcast camera outputs and professional media matrices.

To ensure mission-critical hardware reliability and prevent continuous broadcast distribution failures, all models in the SDE-16265 series are standard-equipped with a dual power supply architecture featuring 1:1 redundancy. This professional layout ensures that if the primary AC power line drops or a power module fails, the secondary backup power supply instantly takes over the full operational load without causing any device reboot, stream dropped packets, or system downtime.

The advanced donanımsal encoding core comprehensively supports next-generation H.265 (HEVC) as well as standard H.264 (AVC) video compression protocols. By leveraging high-efficiency H.265 encoding algorithms, the device achieves up to a 50% reduction in required network transmission bandwidth compared to legacy standards while preserving the exceptional visual clarity and color depth required for professional source workflows.

Adhering strictly to professional B2B telecom specifications, the egress network processing tier supports an extensive array of streaming transport protocols. It natively delivers live streams over SRT (Secure Reliable Transport), HTTP, RTSP, RTMP, RTMPS, HLS, UDP, and RTP protocols in both Multicast and Unicast topologies, adapting seamlessly to local LAN distributions or public cloud ingest points.

For remote site contribution or transmission over unpredictable public networks, the series fully utilizes its integrated SRT (Secure Reliable Transport) engine. SRT applies advanced ARQ (Auto Repeat Request) packet recovery mechanisms to actively counteract network jitter and packet loss, while supporting industry-standard AES encryption to guarantee absolute end-to-end data security.

The audio processing block extracts digital audio directly from the embedded SDI input signals. It natively supports standard broadcast compression formats—predominantly AAC, AAC+, AAC++, MP3, and MP2—giving headend engineers full control over independent audio bitrates, volume gain adjustments, or stereo/mono configurations per stream profile.

Core system parameters, SDI input signal locking status, encoding bitrates, and egress IP routing parameters are configured and monitored exclusively via an embedded WebGUI using a standard web browser over a dedicated, independent Ethernet management interface. This setup eliminates any complex software installations, providing an isolated and highly secure control plane for network administrators.

The BLANKOM SDE-16265 is a high-density, carrier-grade 16-channel IPTV encoding system housed in a permanent 3U 19-inch rackmount chassis. It is engineered to consolidate 16 independent SDE-265 motherboard modules into a single central chassis. Driven by a dedicated dual industrial power supply architecture and featuring advanced H.265/HEVC compression, it serves as a premium micro-headend solution for telecommunication operators, high-density hospitality networks, and enterprise-grade multi-channel IP distribution.

Engineered for mission-critical reliability, the SDE-16265 is equipped with dual (redundant) internal industrial-grade power supplies configured in a hot-standby, balanced layout. If one power unit experiences an unexpected electrical failure or a phase drop, the secondary power supply instantly assumes the complete operational load. This prevents voltage fluctuations, system reboots, or packet drops across the 16 encoder blades, ensuring continuous service delivery.

The SDE-16265 utilizes a completely isolated multi-blade modular architecture. Each of the 16 internal motherboard modules functions as an independent hardware entity running its own standalone embedded Linux OS. Each blade features its own dedicated physical inputs, physical RJ45 network streaming ports, and unique IP addresses, allowing network engineers to independently configure, monitor, or reboot any single channel without interrupting the live streaming services of the other 15 channels.

Each independent SDE-265 module natively supports video inputs and processing configurations up to 1920×1080 Full HD at 60 frames per second (1080p60). The internal system-on-chip (SoC) layout is backward compatible with 1080i, 720p, and standard definition formats, allowing for flexible multi-source digital integration per slot.

To ensure maximum bandwidth efficiency alongside wide client compatibility, every module supports both H.265/HEVC (Main Profile) and H.264/AVC (High/Main/Baseline Profile) video encoding. Audio payloads are compressed utilizing high-fidelity AAC-LC and MPEG-1 Layer II (MP2) standards, multiplexing the stereo audio track directly into the outgoing digital IP transport container to preserve absolute lip-sync tracking.

Each independent SDE-265 motherboard blade incorporates an advanced multi-stream processing engine capable of generating up to 4 distinct, independent IP transport streams simultaneously from its single physical input source. This allows network operators to output a primary high-bitrate 1080p60 stream for primary display arrays while outputting up to three separate lower-bitrate sub-streams optimized for localized monitoring, mobile web proxies, or edge archival NVR loops.

Each internal encoder blade integrates a flexible multi-protocol streaming matrix. Every channel can distribute its processed transport streams simultaneously across various professional protocols, including UDP/RTP (Multicast and Unicast), SRT (Secure Reliable Transport), RTSP, HTTP, and RTMP/RTMPS, enabling parallel delivery to internal local IPTV networks and external public cloud CDNs.

Yes, every individual encoding channel features its own integrated hardware OSD (On-Screen Display) engine. Administrators can independently overlay customized text lines, live system timestamps, channel watermarks, or corporate logos directly onto each video stream matrix via the respective web panel on the fly without causing processing latency or stream stuttering.

There are no mandatory third-party software or SNMP agent dependencies. Because each blade operates on its own embedded firmware, all individual encoding bitrates (CBR/VBR), resolution downscaling, protocol destinations, and audio mapping are managed completely remotely via an intuitive, responsive browser-based WebGUI (Web User Interface) accessed directly through each channel’s respective Ethernet management interface.

Deploying 16 individual portable encoders creates severe server room vulnerabilities, including massive power cable clutter, multiple external “power brick” failure points, uneven airflow, and high accidental disconnection risks. The SDE-16265 solves this by centralizing 16 enterprise channels into a standardized 3U 19-inch kabinet rack footprint. Its passive thermal ventilation design, coupled with hot-swappable dual industrial power supplies, provides the physical stability, clean cable dressing, and mission-critical hardware protection required by telco-grade standards.
