SDI to IP Encoder & Streamer | SDE-265
BLANKOM
Introducing the BLANKOM SDE-265, the ultimate solution for high-quality video streaming. This cutting-edge IP streaming encoder offers perfect video quality and stable operation, ensuring your broadcasts are professional and reliable. With its HDMI-Input Streamer capabilities, you can seamlessly connect your devices for effortless streaming.
Designed for ease of use, the BLANKOM SDE-265 is simple to set up, making it ideal for both novice and experienced users. Its long-lasting durability guarantees that you can rely on this encoder for all your streaming needs, whether for live events, broadcasts, or any HDMI encoder applications.
What truly sets the BLANKOM SDE-265 apart is its exceptional after-sales support from Germany, giving you peace of mind with your investment. Elevate your streaming experience with the BLANKOM SDE-265 – the perfect IP streamer encoder with SDI input for all your video needs.
All BLANKOM encoders offer perfect image quality and stable system operation at an affordable price.
| Inputs | SDI, SDI embedded audio, external analog stereo input by 3.5mm jacks |
|---|---|
| Outputs | GbE IP (up to 4 IP Streams), SDI Loop-through output |
| Outstanding features | SDE-265 supports a maximum resolution of 1920×1080@60fps at the input, and at the output. It works with stream protocols SRT / HTTP / HLS / FLV / RTSP / RTMP / RTMPS / UDP/RTP (Unicast/Multicast) and ONVIF. The SDE-265 is compatible with online live-streaming services, such as YouTube, Facebook, Ustream, and others. |
1080p60 Full HD H.265 (HEVC) and H.264 IP Encoder & Streamer with 4 Streams Output
1080p (2K) High Definition (HD) SDI to IP encoder & streamer for live broadcasting platforms and Video-over-IP applications. Up to 1920*1080@60fps Full-HD resolution. Very stable operation on multicast distribution on local area networks. Suitable for Video-over-IP application through the internet. 4 IP output streams at the same time with different resolutions, e.g. for LAN, YouTube, Facebook, Twitch simultaneously. Supports SRT protocol (SRT Encoder).
BLANKOM SDE-265 SDI Encoder serves the distribution of SD and HD TV/video content through IP networks in digital quality. The live video can be received by Internet media server by TV sets with IPTV Set-Top Boxes, on PC’s and tablets with VLC Player.
Streamer for OTT platform providers for feeding the CDN with live video.
Streamer for multicast IPTV distribution on LAN.
Encoder for Video-over-IP applications. Suitable for use on Ka-Sat live feeds.
Application examples:
- IPTV (Wowza, Xtream Codes Media Server, …)
- Online Live Broadcast (YouTube, Facebook, Ustream, Twitter, …)
- NVR (Network Video Recorder)
- Recording System / Software
- Digital Signage
- Education / Campus Broadcast
- Hotel TV system
- Video Conference
BLANKOM SDE-265 IPTV SDI encoder is designed for TV signal distribution in excellent quality over LAN and INTERNET.
The h.264 and h.265 (HEVC) compression technology features low-latency and low bit rates for IPTV/OTT systems. The high-efficient encoding chips saves bandwidth cost throughout all its resolution range.
Distribution of SD and HD TV channels through the IPTV/OTT network using state-of-art IP technology from almost any kind of video input.
Excellent video and audio quality.
High reliability. No regular service and maintenance needed during operation.
From 1 input signal, 4 entirely different streams can be generated. The main stream can have up to Full HD (1080p), the secondary streams up to 720p HD resolution.
On screen logo and text insertion. Through HLS encoding feature, Android and iOS mobile devices compatible.
The uni- and multicast streams can be assigned with DVB-conform table content to allow the integration into multiplexes of IP to DVB-Modulators.
The easy configuration is designed by a simple Web-interface application compatible with nearly every browser.
Function: H.265 (HEVC) & H.264 Encoder and IP Streamer
INPUT
- One 3G SDI input
- Input Resolution 1080p, 1080i, 720p and below
- Separate audio input with level adjustment (3.5 mm L/R Analog Audio line in)
- Embedded audio from SDI signal or external audio can be selected
OUTPUT
- Simultaneous 4 different streams output (Main stream and 3 Secondary streams)
- SDI loop through output
- Each stream can be H.265 (HEVC) or H.264 encoded
- Video data rate: 0.1 Mbps ~ 32 Mbps
- Video frame rate: 5 ~ 60 fps
- Bit rate control: VBR, CBR
- Output Resolution 1080p, 1080i, 720p and below (max 1080p@60fps on main stream)
- Main Stream output resolution support: 1920×1080, 1680×1056, 1280×720, 1024×576, 850×480, 720×576, 720×540, 720×480, 720×404, 704×576, 640×480, 640×360, 608×448, 544×480, 480×480, 480×384, 480×360, 480×320, 480×272, 480×270, 400×320, 400×224, 352×480, 352×228, 320×256, 320×240, 320×180, 240×180, 176×144.
- Low latency: 700 … 800 ms (800 ms in avg.) (RTMP)
SYSTEM
- Protocol HTTP / SRT / HLS / FLV / RTSP / RTMP / RTMPS / UDP/ RTP (Unicast/Multicast) Stream Protocols and ONVIF
- Video encoder HEVC (H.265) or H.264 (MPEG-4, AVC) high, main, baseline profile, MJPEG/JPEG baseline
- Audio encoder AAC/AAC+/AAC++/MP3/MP2/AC3 G711
- Data interface RJ45, 1 Gbps Ethernet interface, Control over web browser
- Rate control CBR/VBR
- GOP Structure IBBP Adv
- Pretreatment De-interlacing, Noise reduction, Sharpening
- Sampling rate Auto
- Audio Bit-rate 48K/64K/96K/128K/160K/192K
- Audio Sampling precision 24 bit
- Audio Data Rate 12 kbps ~ 640 kbps
- User interface WEB GUI
- Logo (as *.bmp file) and Text insertion feature on main stream & on 2nd stream
- Firmware upgrade support
GENERAL
- Power supply 12V DC, 1A
- Dimensions 170 × 130 × 30 mm
- Weight 300g
- Consumption 6W
Specifications are subject to change without prior notice.
