BLANKOM IGS-2000 / IGS-4000 / IGS-6000

BLANKOM IGS-2000 is a professional integrated ASI and IP decoder for broadcasters with dual ASI and GigE IP inputs.

It is at the same time a full professional bi-directional ASI-to-IP Converter and IP-to-ASI Converter.

Output is HD-SDI with max. 2 stereo pairs (AC3 passing supported) each SDI and ASI as well as IP multiplexed.

IGS-4000 has 4 HD-SDI outputs, and IGS-6000 has 6 HD-SDI outputs.

Interfaces

2x IP input and 1 IP output
2x Bi-directional ASI ports with input or output mode selectable
2x HD/SD-SDI decoding output with 2 stereo Audio’s embedded in each port
Ordering guide

BLANKOM IGS-2000 with 2 SDI out
BLANKOM IGS-4000 with 4 SDI out
BLANKOM IGS-6000 with 6 SDI out

Share this product

ASI and IP Decoder with 2, 4, or 6 SDI Outputs, IP to ASI Converter, ASI to IP Converter



BLANKOM IGS-2000/4000/6000 series is a new design professional ASI Decoder, IP Decoder, ASI to IP Converter, and IP to ASI Converter in one unit. It can receive UDP IP streams as well as dual ASI streams. After de-multiplexing, it gives content out as decoded service through HD/SD-SDI, ASI and IP outputs.

BLANKOM IGS-2000 ASI to IP Converter, Gateway

  • IP and ASI Decoder, ASI to IP Converter, and IP to ASI Converter in one unit
  • 2x bi-directional ASI ports with input or output mode selectable
  • 2x IP input and 1x IP output
  • 2x HD/SD-SDI decoding output
  • UDP Unicast/Multicast
  • Broadcast quality
  • H.264 and MPEG-2 Decoding
  • Embedded Re-multiplexer
  • CC (Closed Caption)/Subtitle Support
  • AC3 pass-through
  • Web Management
  • NMS/SNMP Network Management



BLANKOM IGS-2000 ASI to IP Converter, Gateway Block Diagram

BLANKOM IGS-2000 ASI to IP Converter, Gateway



BLANKOM IGS-2000 ASI to IP Converter, Gateway



Function: Broadcast grade decoder with IP and ASI inputs, multiple HD-SDI, ASI and IP outputs

INPUT

  • 2 IP (MPTS/SPTS, 100M/1000Mbps Ethernet, RJ45, UDP protocol, Unicast/multicast)
  • Max.2x ASI selectable as either In- or Out, BNC 75 Ω

DECODING

  • 480i,480p,576i,576p,720p@50/59.94/60, 1080i@50/59.94/60
  • Video: HD/SD MPEG-2 and MPEG4 AVC/H.264
  • Audio: Dual stereo audios embedded in each port with MPEG1 Layer2, LC-AAC, HE-AAC, AC3 (2.0/5.1), AC3 Pass-through

CONTROL PORT

  • Ethernet Port 100BaseT RJ45

OUTPUT

  • 0…2x ASI as in- or output on BNC interfaces selectable
  • Video: 2x HD/SD-SDI (BNC) ( 4 / 6 for 4000/6000 Model)
  • IP Out on GigE: 1 (2,3) x MPTS outputs per module on GbE RJ45 interface (UDP multicast)

SYSTEM

  • Control Management: Network (NMS)
  • Web-based Management
  • Ethernet port for CPU/FPGA firmware upgrade

GENERAL

  • Dimensions: 328 mm × 482 mm × 45 mm, 19” 1RU, 2,5 kg
  • Power: AC 110V±10%,50/60Hz or AC 220V±10%, 50/60Hz, Consumption: < 25 W
  • Temperature: 0~45℃ (operation)

Specifications are subject to change without prior notice.

BLANKOM IGS-2000 ASI to IP Converter, Gateway Application Example

The BLANKOM IGS-2000 / IGS-4000 / IGS-6000 series consists of professional, bidirectional ASI-to-IP and IP-to-ASI gateways designed to bridge legacy broadcast distribution systems with modern IP transport networks. They ingest Asynchronous Serial Interface (ASI) transport streams from broadcast equipment and encapsulate them into linear IP streams, or conversely, receive IP streams and decode them back into physical ASI outputs via BNC interfaces.

The product family is structured hierarchically to meet distinct deployment scales within a standard 1U rack-mount chassis. The channel density scales across the series: the IGS-2000 handles basic-density conversion, the IGS-4000 addresses mid-tier multi-channel requirements, and the top-tier IGS-6000 model maximizes physical ASI BNC interface aggregation, satisfying high-capacity enterprise broadcast centers and telecommunication facilities.

Yes, depending on the software configuration and the specific hardware module layout selected during the project procurement phase, variants within this series support independent bidirectional data processing. This enables broadcast engineers to run simultaneous ASI-to-IP ingestion and IP-to-ASI egress processing through the same 1U chassis without crossing signal paths or causing processing bottlenecks.

Every physical ASI BNC port on the chassis operates at full broadcast line-rate, supporting a maximum throughput of up to 216 Mbps. Furthermore, the embedded processing fabric automatically detects, parses, and converts both standard 188-byte and legacy 204-byte (Reed-Solomon encoded) Transport Stream packet structures seamlessly, ensuring perfect signal compliance.

The egress streaming block complies strictly with professional telecom B2B IP networking specifications. It implements low-overhead, line-rate UDP and RTP encapsulation, supporting both Unicast and Multicast transport topologies. This ensures highly stable, low-latency distribution across gigabit local architectures or core telecom multi-protocol networks.

No, the processing delay is practically negligible. Because the gateway does not parse or process the upper-layer syntax of the Transport Stream (such as video decoding, audio parsing, or PID reindexing), it operates at wire-speed line-rate processing. The encapsulation of an incoming physical ASI stream into IP packets (and vice versa) happens instantly at the hardware/MAC layer, preserving the ultra-low latency required for live synchronization and real-time broadcast contribution links.

When performing IP-to-ASI de-encapsulation, the gateway utilizes specialized internal buffering algorithms to absorb network-induced packet jitter caused by IP routing layers. It accurately reconstructs the native PCR (Program Clock Reference) timing of the original Transport Stream, generating a perfectly stable, continuous physical ASI clock rate at the BNC output. This prevents buffer underrun or overflow errors on downstream legacy modulators or IRDs.

The series natively accommodates both Constant Bit Rate (CBR) and Variable Bit Rate (VBR) ASI transport streams. In ASI-to-IP encapsulation mode, the device encapsulates the incoming packet blocks transparently as they arrive at the physical BNC interface. If a VBR stream is ingested, the outgoing IP data rate dynamically scales to match the exact payload throughput, ensuring optimal bandwidth utilization on your IP backhaul without dropping empty or null packets that are critical for specific broadcast multiplexes.

Remote configuration, real-time input bit-rate tracking, port logging, and packet statistics are managed exclusively via an embedded WebGUI through a standard internet browser over a dedicated, independent 100M Ethernet management interface. This model line does not support SNMP management, prioritizing low-overhead web-based administration and keeping the control plane completely secure and isolated.

Built for continuous 24/7/365 operator uptime, all variants are enclosed in a rugged, standard 19-inch 1U rack-mount industrial chassis. Detailed Ordering Guides on irenis-blankom.com outline the available hardware matrix cards and options for dual redundant power supplies (AC/DC) to protect the distribution path against single points of failure in primary telecom facilities.
