BLANKOM IGS-900 DVB to IP Gateway

DVB to IP GATEWAY, 16 Tuner | IGS-900

BLANKOM IGS-900

BLANKOM IGS-900 DVB/IP gateway has 3 versions either with 512 SPTS or with 16 MPTS IP capacity.

Supports up to 128 PID mapping per input.

It has 16 DVB-S/S2 tuners built inside, thus can receive 512 different programs from 16 different transponders.

Features

16 Tuner inputs DVB-S/S2/S2x (DVB-C, DVB-T/T2, ISDB-Tb optional)
2 ASI inputs
IP (512 SPTS or 16 MPTS) over UDP, RTP / RTSP output
BISS descrambling
DiSEqC support for up to 4 Satellites
2 GbE mirrored output, up to 850 Mbps (SPTS)
2 independent GbE output port, GE1 + GE2 (MPTS)

Ordering guide

BLANKOM IGS-900 – IP (512 SPTS), 16 DVB-S/S2/S2X Tuner + 2 ASI input, SPTS output
BLANKOM IGS-900 MPTS (Mode 2) – IP (14 MPTS), 14 DVB-S/S2/S2X Tuner + 2 ASI input, MPTS output
BLANKOM IGS-900 MPTS (Mode 3) – IP (16 MPTS), 16 DVB-S/S2/S2X Tuner input, MPTS output
BLANKOM IGS-900C – IP (512 SPTS), 16 DVB-C/T/ISDB-T Tuner + 2 ASI input, SPTS output
BLANKOM IGS-900C MPTS (Mode 2) – IP (14 MPTS), 14 DVB-C/T/ISDB-T Tuner + 2 ASI input, MPTS output
BLANKOM IGS-900C MPTS (Mode 3) – IP (16 MPTS), 16 DVB-C/T/ISDB-T Tuner input, MPTS output
BLANKOM IGS-900A – IP (512 SPTS), 16 ATSC Tuner + 2 ASI input, SPTS output
BLANKOM IGS-900A MPTS (Mode 2) – IP (14 MPTS), 14 ATSC Tuner + 2 ASI input, MPTS output
BLANKOM IGS-900A MPTS (Mode 3) – IP (16 MPTS), 16 ATSC Tuner input, MPTS output

Share this product

DVB to IP Gateway with 16 Transponder input



Designed for local IPTV distribution networks on LAN’s and for OTT operators, BLANKOM IGS-900 is converting up to 512 channels from 16 satellite transponders into IPTV signals, at an unbeatable price.

BLANKOM IGS-900 DVB to IP Gateway, front view

  • 16 Tuner inputs DVB-S/S2/S2X (DVB-C, DVB-T, ISDB-T, ATSC Optional)
  • 2 ASI input
  • BISS descrambling
  • 90 Mbps max bitrate per each input
  • FTA only
  • 3 versions:
  • IGS-900: IP (512 SPTS) — 16 Tuner + 2 ASI input / SPTS output
  • IGS-900 MPTS (Mode 2) : IP (14 MPTS) — 14 Tuner + 2 ASI input / MPTS output
  • IGS-900 MPTS (Mode 3) : IP (16 MPTS)  — 16 Tuner input / MPTS output
  • Supports maximum 128 PID mapping per input
  • DiSEqC support for up to 4 Satellites
  • 2 GE mirrored output, up to 850 Mbps (SPTS version)
  • 2 independent GE output port, GE1 + GE2 (MPTS version)
  • Accurate PCR adjusting (SPTS version)
  • PID filtering and re-mapping (SPTS version)
  • PSI/SI rebuilding and editing (SPTS version)
  • “Null PKT Filter” function (MPTS version)
  • Remote control and firmware, web NMS management
  • Updates via web
  • Professional quality, breakthrough price

    •





BLANKOM IGS-900 DVB to IP Gateway, System diagram

Converting the content of 16x fta satellite transponders into IP, for generating SPTS or MPTS IPTV content.



BLANKOM IGS-900 is a DVB/IP Gateway, which has 16 DVB-S/S2 tuners (DVB-C, DVB-T, ISDB-T, ATSC optional) and de-multiplexing functions in one case to convert RF signals into TS output.

It is in a 1U case which supports 16 tuner inputs.

To meet customers various requirements, IGS-900 is designed to de-mux programs from any RF input.
It is capable to generate either 512x SPTS streams or 16x MPTS streams in UDP, RTP/RTSP.



BLANKOM IGS-900 DVB to IP Gateway, front view



BLANKOM IGS-900 DVB to IP Gateway, rear view



Function DVB / IP Gateway with 16x RF input, IP port.

INPUT

  • RF 16x RF DVB-S/S2/S2X (DVB-C, DVB-T, ISDB-T, ATSC optional), F type
  • 90 Mbps max. bitrate per each input

TUNER

  • DVB-S
    Input frequency: 950-2150 MHz
    Symbol rate: 2-45 Msps
    Signal strength: -65 -25 dBm
    Constellation: ½, 2/3, ¾, 5/6, 7/8 QPSK
  • DVB-S2
    Input frequency: 950-2150 MHz
    Symbol rate: QPSK 1-45 Msps, 8PSK 2-30 Msps
    Code rate: ½, 3/5, 2/3, ¾, 4/5, 5/6, 8/9, 9/10
    Constellation: QPSK, 8PSK
  • DVB-C (optional)
    J.83A (DVB-C), J.83B, J.83C 47 – 860 MHz
    Constellation: 16/32/64/128/256 QAM
  • DVB-T/T2 (optional)
    44 – 1002 MHz
    Bandwidth: 6, 7, 8 MHz

OUTPUT

  • IP (512 SPTS or 16 MPTS) over UDP, RTP / RTSP output
  • SPTS version (Mode 1) : 16 DVB-S/S2x tuners input +2 ASI input — SPTS output
  • MPTS version (Mode 2): 14 DVB-S/S2x tuners input +2 ASI input — MPTS output
  • MPTS version (Mode 3): 16 DVB-S/S2x tuners input — MPTS output
  • 2x 1000M Base-T Ethernet interface (unicast/multicast)
  • 2x 800 Mbps max. output bitrate
  • Control over network management (WEB NMS), English menu

GENERAL

  • Dimensions 482mm × 410mm × 44mm, 19” 1U, 3.6 kg
  • Power AC 110V±10%,50/60Hz or AC 220V±10%, 50/60Hz
  • Temperature 0~45℃ (operation)

Specifications are subject to change without prior notice.
