BLANKOM IGS-924 DVB to IP gateway has 1024 SPTS or with 26 MPTS IP capacity. Supports PID filtering, re-mapping. It has 24 DVB-S/S2 tuners built inside, thus can receive 1024 different programs from 24 different transponders.BLANKOM IGS-924 is a DVB/IP Gateway, which has 24 DVB-S/S2/S2X or DVB-C/T/T2/ISDB-T tuners and de-multiplexing functions in one case to convert RF signals into TS output. The device converts the content of 24x fta satellite transponders into IP, for generating SPTS or MPTS IPTV content.It is in a 1U case which supports 24 tuner inputs.To meet customer’s various requirements, IGS-924 is designed to de-mux programs from any RF input.It is capable to generate either 1024 SPTS streams or 26 MPTS streams in UDP, RTP/RTSP.
BLANKOM IGS-900 DVB/IP gateway has 3 versions either with 512 SPTS or with 16 MPTS IP capacity.Supports up to 128 PID mapping per input.It has 16 DVB-S/S2 tuners built inside, thus can receive 512 different programs from 16 different transponders.
BLANKOM IGS-700/84 DVB to IP Gateway can stream a maximum of 64 SPTS and 2 MPTS IP streams, also available in parallel from 2 ASI ports.Additional services such as IP in (64 SPTS / 2 MPTS) and 2 ASI can be combined or re-multiplexed.The processor supports up to 512 PID mapping. Each input can be decrypted with a multiservice decryption (MSD) using a CA module (up to 4 CI slots).
The full-featured BLANKOM HDM-9500 Modulator is ideal for small CATV head end systems, and it's a smart choice for hotel TV systems, entertainment systems in sports bars, hospitals, and apartment complexes. It is a simplified, lower cost version of the HDM-9400 Modulator family.
The full-featured BLANKOM HDM-9400 Modulator is ideal for small CATV head end systems, and it's a smart choice for hotel TV systems, entertainment systems in sports bars, hospitals, and apartment complexes. The HDM-9400 is our most versatile modulator, offering a broad range of options.
BLANKOM HDC-7024A is a 5th generation SAT & IPTV to QAM transmodulator with multiplexer and scrambler. The IPTV input channels can be SPTS or MPTS, unicast or multicast. The internal multiplexer creates 16 RF + streams with any combination of content. The output consists of 16 DVB-C carriers within 192 MHz bandwidth, each with up to 256QAM modulation. Each of the 16 output multiplexes are also provided as MPTS IPTV streams, UDP/RTP/RTSP, unicast or multicast at both the data ports.
BLANKOM HDC-7016A is a 5th generation SAT & IPTV to QAM (DVB-C) transmodulator with multiplexer and scrambler. The IPTV input channels can be SPTS or MPTS, unicast or multicast. The internal multiplexer creates 16 RF + streams with any combination of content. The output consists of 16 DVB-C carriers within 192 MHz bandwidth, each with up to 256QAM modulation. Each of the 16 output multiplexes are also provided as MPTS IPTV streams, UDP/RTP/RTSP, unicast or multicast at both the data ports.
BLANKOM HDC-6008CI is a next generation cable-tv headend system, in one unit.Satellite and IPTV channels can be combined in 4 different DVB-C groups and distributed over coaxial cable to large networks.
Introducing the BLANKOM HDC-5004 IP to QAM Modulator, a cutting-edge solution designed for seamless integration of IPTV channels into DVB-C formats. This versatile modulator features an internal multiplexer and scrambler, allowing you to multiplex and modulate up to 512IPTV channels into 4 DVB-C channels effortlessly.With configurable RF frequencies, the HDC-5004 ensures optimal performance tailored to your specific requirements. Enjoy the convenience of remote control through any web browser, making management simple and efficient. This advanced unit supports both SPTS and MPTS input channels, whether unicast or multicast, providing flexibility in content delivery.Experience the power of BLANKOM® Hybrid DVB & IPTV Headend Technology with the HDC-5004. Its internal multiplexer expertly creates 4 streams from a variety of content combinations, ensuring a robust and dynamic broadcasting experience. Elevate your broadcasting capabilities with the BLANKOM HDC-5004 IP to QAM Modulator, the ideal edge QAM solution for transforming IP sources into superior DVB-C outputs.It also has MPTS stream output of the multiplexed channels. Thus, it can be used as SPTS in MPTS out IPTV Multiplexer.The unit can be controlled remotely through the web, with any web browser.Application:- IP to QAM conversion at headends
- Edge QAM on CATV networks
- Multiplexing SPTS IPTV channels into MPTS IPTV streams
Introducing the BLANKOM HDC-5000 Series IP to QAM Modulator, a cutting-edge solution designed for seamless integration of IPTV channels into DVB-C formats. This versatile modulator features an internal multiplexer and scrambler, allowing you to multiplex and modulate up to 1024 IPTV channels into 16 to 64 DVB-C channels effortlessly.With configurable RF frequencies, the HDC-5000 ensures optimal performance tailored to your specific requirements. Enjoy the convenience of remote control through any web browser, making management simple and efficient. This advanced unit supports both SPTS and MPTS input channels, whether unicast or multicast, providing flexibility in content delivery.Experience the power of BLANKOM® Hybrid DVB & IPTV Headend Technology with the HDC-5000 series. Its internal multiplexer expertly creates depending on the used model, 16/32/48/64 streams from a variety of content combinations, ensuring a robust and dynamic broadcasting experience. Elevate your broadcasting capabilities with the BLANKOM HDC-5000 Series IP to QAM Modulator, the ideal edge QAM solution for transforming IP sources into superior DVB-C outputs.It also has MPTS stream output of the multiplexed channels. Thus, it can be used as SPTS in MPTS out IPTV Multiplexer.The unit can be controlled remotely through the web, with any web browser.Application:- IP to QAM conversion at headends
- Edge QAM on CATV networks
- Multiplexing SPTS IPTV channels into MPTS IPTV streams
