BLANKOM EMU-9504/EMU-9508/EMU-9512

The BLANKOM EMU 9500 series IPTV Encoder is a high-quality HD audio and video encoding device with SDI inputs. Furthermore, it is a streaming device, supporting UDP (SPTS), SRT, RTP, RTSP, RTMP, HTTP, HLS Protocols.

Features	4/8/12 HDMI Inputs 4/8/12 SPTS IP Output Streaming Protocols
Ordering guide	EMU-9504: 4 SDI Inputs EMU-9508: 8 SDI Inputs EMU-9512: 12 SDI Inputs

IPTV Encoder with 4, 8 or 12 HDMI Inputs, SPTS encoding, Streaming Function

The BLANKOM EMU 9500 series has 4, 8 or 12 HDMI compatible video input interfaces and supports both HEVC/H.265 and MPEG 4 AVC/H.264 video encoding and MPEG 1 Layer 2 audio encoding. This compact encoder can simultaneously convert 4/8/12 HD Video & Audio signals from HDMI inputs to IP output as a multiplexed MPTS and SPTS IP output streams. Text, graphics or QR-code can be added to every video picture.

Its high-integrated and cost-effective design fits perfectly into various digital distribution systems, such as cable TV digital Headend and satellite digital TV broadcasting.

EMU-8200 series is the similar unit, without streaming protocols support, with HD-SDI instead of HDMI inputs.

BLANKOM EMU-9504 IPTV Encoder

4/8/12 HDMI Inputs
4/8/12 SPTS IP Stream Output
IP Output over UDP (SPTS), SRT, RTP, RTSP, RTMP, HTTP, HLS Protocols (Streaming)
HEVC/H.265 and MPEG 4 AVC/H.264 video encoding formats
3 versions:
EMU-9504: 4 HDMI Inputs, 4 SPTS IP Stream Output
EMU-9508: 8 HDMI Inputs, 8 SPTS IP Stream Output
EMU-9512: 12 HDMI Inputs, 12 SPTS IP Stream Output
Logo/Text injection to the encoded videos
MPEG-1 Layer 2, LC-AAC, HE-AAC and AC3 Pass through Audio encoding, audio gain adjustment
Web-based Network management
Professional quality, breakthrough price

Features

4, 8 or 12 SDI input IPTV Encoder and Streamer with Text and Graphic Logo-Insertion

Supports UDP (SPTS), SRT, RTP, RTSP, RTMP, HTTP, HLS Protocols (Streaming)

Front Panel

BLANKOM EMU-9504 IPTV Encoder

Technical Specifications

Function IPTV Encoder with Streaming Function

Input	4/8/12 HDMI inputs for option, HDCP 1.4
Video Encoding	Encoding Format	HEVC/ H.265 , MPEG 4 AVC/H.264
	Resolution	Input		Output
				HEVC/H.265	MPEG-4 AVC/H.264
		4*1080P-50		4*1080P-50	2*1080P-50
		4*1080P-60		4*1080P-60,	2*1080P-60
		4*1080I-50		4*1080P-50	41080I-50 21080P-50
		4*1080I-60		4*1080P-60	41080I-60 21080P-60
		4*720P-50		4*720P-50	4*720P-50
		4*720P-60		4*720P-60	4*720P-60
	Chroma	4:2:0
	Bitrate	0.5Mbps~20Mbps(each channel)
	Rate Control	CBR/VBR
	GOP Structure	IBBP, IPPP
	Advanced Pretreatment	De-interlacing, Noise Reduction, Sharpening
Audio Encoding	Encoding Format	MPEG-1 Layer 2, LC-AAC, HE-AAC, HE-AAC V2, AC3 Pass-through
	Sampling rate	48KHz
	Bit-rate (each channel)	48Kbps~384Kbps (MPEG-1 Layer 2& LC-AAC) 24 Kbps~128 Kbps (HE-AAC) 18 Kbps~56 Kbps (HE-AAC V2)
	Audio Gain	0~255
Stream output	IP output over UDP (SPTS), SRT, RTP, RTSP, RTMP, HTTP, HLS Protocols, 1000M/100M Base-T Ethernet interface (unicast/multicast); IPv4, IPv6 output IP null packet filter
System	Web-based management
	English control interface
	Ethernet software upgrade
Miscellaneous	Dimension (W× L× H)		482mm×328mm×44mm
	Approx weight		5kg
	Temperature		0~45℃(work), -20~80℃（Storage）
	Power		AC 100V-220V±10%, 50/60Hz
